| Name | Value |
|---|---|
| Bearing number | NCF 29/900 V |
| Size (mm) | 900x1180x165 |
| Brand | MBY |
| Bore Diameter (mm) | 900 |
| Outer Diameter (mm) | 1180 |
| Width (mm) | 165 |
| Name | Value |
|---|---|
| d | 900 mm |
| D | 1180 mm |
| B | 165 mm |
| d1 | - 996 mm |
| D1 | - 1096 mm |
| E | 1120 mm |
| s | 13 mm |
| r1,2 | min. - 6 mm |
| r3,4 | min. - 6 mm |
| da | min. - 923 mm |
| das | 982 mm |
| Da | max. - 1127 mm |
| Db | max. - 1127 mm |
| ra | max. - 5 mm |
| rb | max. - 5 mm |
| Basic dynamic load rating | C - 5940 kN |
| Basic static load rating | C0 - 14600 kN |
| Fatigue load limit | Pu - 950 kN |
| Reference speed | 170 r/min |
| Limiting speed | 220 r/min |
| Calculation factor | kr - 0.2 |
| Calculation factor | e - 0.3 |
| Calculation factor | Y - 0.4 |
| Mass bearing | 472 kg |
